Marka |
KIN-UNICO |
|
Model no. |
KU200ZH-A |
|
Product Technical Specifications(General Information) |
|
Part I
Technical Design |
Application |
Cargo&passengers Transport |
|
Design Max Speed |
¡Ý60 km/h |
|
Loading Capacity |
¡Ý 500kg |
|
Unladen Kerb Weight |
320 kg |
|
Dimension(L*W*H) |
3155x1250x1430 mm |
|
Color |
Red/Green/Yellow/Black/Other colors |
|
Track |
1050 mm |
|
Wheel Base |
2100 mm |
|
Ground Clearance |
160 mm |
|
Brake Mode |
Front&Back wheels, Drum |
|
Transmission Type |
Shaft Drive |
|
Power |
8.0 kw |
|
Cool Type |
Water Cooled |
|
Min.Fuel Consumption |
354g kw.h |
|
Fuel Type |
Gasoline |
|
Fuel Tank Capacity |
12 L |
|
Part II
Engine Details |
Engine Type |
Single cylinder,4-stroke,camshaft downward |
|
Bore Stroke |
63.5¡Á49.5mm |
|
Fuel Type |
Gasoline |
|
Compression Ratio |
9.5:1 |
|
Rated Power&Rotating Speed |
8.0 kw /8000rpm |
|
Max.Torgue/Rotating Speed |
11.0N.m /6500rpm |
|
Lowest No-Load Speed Stability |
1500rpm |
|
Displacement(cc) |
200cc |
|
Ignition System |
CDI |
|
Apply to |
Motor tricycle |
|
Starter |
Kick/Electric |
|
Part III
Operation |
Starting System |
Electric/Kick |
|
Transmission |
5 Forward &1 Reserse Gears |
|
Gearshift Control |
Manual-Foot |
|
Clutch Method |
Manual-Hand |
|
Brake Operate Mode |
Manual-Hand or Foot |
|
Part IV
Packaging |
Package |
Protective Packaging |
|
Loading Capacity (CKD) |
24 units in 20"GP,60Units in 40"HQ |
|
Delivery Time (from loading port) |
20-25 Days after receiving advance payment |
|
|
|
